Product Description
Key Features
- Powered by Intel® Socket LGA1851 for Intel® Core™ Ultra Processors
- 4 x DIMM, Max. 128GB, DDR5-5600 Non-ECC, Un-buffered Memory Dual Channel Architecture
- 4 x 3.5” Hot-swap HDD bays (Front)
- 1 x 2.5” Storage Bays (Internal)
- 1 x PCI-E 5.0 x16 (Full Height)
- 2 slot, type 2280 (supports PCIe 4.0 x4 mode)
- Dual Slot Full Height GPU support
- Intelligent Power Recovery after failure, and WoL PXE support
- 750W PSU 80 Plus Gold, 110~240 VAC Full Range
- Efficient cooling with Mini Server Tower Chassis design
- Suitable for AI Inferencing Applications
|
SYSTEM |
|
|
Recommended Operating System |
· Microsoft Windows 11 Professional 64-Bit · Microsoft Windows Server 2025 64-Bit · Red Hat Enterprise Linux · SuSE/Ubuntu/CentOS Linux · vmWare · Citrix XenServer |
|
CPU |
1 x Intel® Core™ Ultra (LGA 1851) Processor Family |
|
System Memory Slot |
4 x Up to 128GB DDR5 5600 Non-ECC U-DIMM |
|
Graphics |
· 1 x DisplayPort 1.4, Max Resolution: 8K 60Hz / 5K 120Hz · 1 x HDMI® port, Max Resolution: 4K 60Hz * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
|
Front I/O Port |
· 2 x USB 3.0 Port |
|
Rear I/O Port |
· 2 x USB 3.2 ports (Type-A) · 1 x Ethernet 10/100/1000Base-T RJ-45 Port |
|
LED |
· Power status · HDD · LANs · System Fail Alert · ID |
|
Expansion Slots |
· 1 x PCI-E 5.0 x16, Full Height |
|
Storage Disk Drive |
· 4 x Front Hot-Swap 3.5”/ 2.5” SATA Storage Bay (RAID 0,1,5,10) · 1 x Internal 2.5” SATA Storage Bay · 1 x M.2 (2280) |
|
Power Supply |
750W 80PLUS Gold Power Supply, 110~240 VAC Full Range |
|
MECHANICAL |
|
|
Dimension |
407 mm x 275 mm x 305 mm (W x D x H) |
|
Mounting |
Desktop |
|
ENVIRONMETAL |
|
|
Operating Temperature |
10°C to 35°C |
|
Storage Temperature |
-40°C to 70°C |
|
Relative Humidity |
20% to 90% non-condensing |
|
REGULATORY APPROVALS |
|
|
Standards |
· CE · FCC |
