Product Description
Physical Port
- 4 x 10/100/1000BASE-T RJ45 (1 x LAN + 1 x WAN + 2 x LAN/WAN/DMZ)
- Multi-WAN function
- Outbound load balancing (Supported algorithms: Auto, Source IP, Destination IP or Manual)
IP Routing Feature
- Static Route
- Dynamic Route (RIPv2)
QoS
- Guaranteed and maximum bandwidth configurable
- Priority rule
- Policy mode
- Inside per source IP mode
- Outside per source IP mode
Firewall Security
- Stateful Packet Inspection (SPI) firewall
- Blocking DoS/DDOS attack
- Internal firewall
- IP address block
- Block website by URL, IP, Domain, FQDN
- Anti-ARP spoofing
- Application control
Mail Security
- Antivirus base on auto-update antivirus engine
- Built-in multiple anti-spam algorithms, auto learning, and personal black/white list
- Mail log
Advanced Security
- IDP (Intrusion Detection and Prevention)
- User Authentication
- Switch co-defense
- Anomalous IP traffic analysis
VPN Features
- Max. Connection Tunnel Entries: 500 IPSec VPN tunnels, 200 PPTP VPN tunnels, 200 L2TP VPN tunnels or 50 SSL VPN tunnels
- Stateful packet inspection
- Encryption methods: DES, 3DES, AES, AES-128/192/256
- Authentication methods: MD5, SHA-1, SHA-256, SHA-512
Networking
- Outbound load balance
- Failover for WAN
- PPPoE/Static IP/DHCP Client
- Protocols: TCP/IP, UDP, ARP, ICMP, FTP, IPv4, IPv6
- Virtual Server
- DDNS: DynDNS, 3322, No-IP, Planet DDNS & Planet Easy DDNS
- Transparent bridge/transparent routing
Others
- Wireless AP Management
- CMS (Central Management System)
- HA (High Availability) mode
- Supported access by HTTP or HTTPS
- SNMP agent (SNMPv3-capable)
- Schedulable firmware upgrade through Web browser
- Comprehensive web-based management and policy setting
- Monitoring, logging, and alarms of system activities
