Product Description
The video wall solution with AG Neovo VWM-01 standard mounting arms suits 42 to 65 inch displays for control rooms and digital signage applications.
The VWM-01 video wall mount bearing up to 80kg of weight, meets the requirements of narrow-bezel or seamless video wall mounting purpose. For multi-display mounting, VWM-01 wall mounts, VWM-02 Push-to- Open mounting arms, WMA-01/02/03 aluminium extension bars and WMA-04 wall brackets can be used together to compose displays in one row. This allows reducing the installation times by refraining from the complicated measuring and calculations on screen spacers, and equally enables in saving alignment time when composing rows of displays.
-
Modular mount for 1 to unlimited wall display configurations
-
Landscape or Portrait screen installation
-
Compatible with VESA standard (Max. 400 x 400 mm)
-
Additional VWM-02 Push-to-Open mounting arms and extension bars available for fast and easy modular installation
-
Weight capacity: 80 kg
| Type | Type: | Video Wall Mounts |
| Mounting | Display: | 46"-55" Displays |
| Loading | Weight Capacity: | 80.0 kg (176.4 lb) |
| Screw Adjustment | Up: | 3.3 mm |
| Down: | 3.3 mm | |
| Right: | 15.0 mm | |
| Left: | 15.0 mm | |
| Exterior | Material: | Steel and Aluminium |
| Colour: | Black and Silver | |
| Dimensions | Product (W x H x D): | 500.0 x 526.0 x 93.0 mm (19.7” x 20.7” x 3.7”) |
| Packaging (W x H x D) (1set): | 560.0 x 90.0 x 250.0 mm (22.0" x 3.5" x 9.8") |
|
| Weight | Net Weight: | 4.5 kg (9.9 lb) |
| Gross weight (1set): | 5.5 kg (12.0 lb) |
