Product Description
VSS-5729 is equipped with 8 SAS/SATA 3.5-inch disk drive bays, and 2.5" hot-swap HDD bays per enclosure. The hot-swappable design provides non-stop high availability, making short work of maintenance. VSS-5729 also offers great freedom when it comes to the choice of operating system drive type and placement, with M.2 slot available, and two hot-swappable 2.5-inch SSD bays.
PIKE II offers the latest 12Gb/s SAS together with PCI-E 3.0 solution. While latest 12Gb/s SAS doubles the data rate running at twice the speed of the previous generation, PCI-E 3.0 offers high reliability and faster speed connection. PIKE II meets user needs with support for 6Gb/s SATA and 12Gb/s SAS storage and integrated RAID data protection. Just placing the PIKE II card can immediately enlarge the capacity, improve the performance, and strengthen the signaling, making it the great upgrade option. Additionally, multiple HBAs allow multi-paths which improve over performance.
Key Features
- Powered by Intel Xeon Scalable Platform
- 2U rack-optimized design
- 8 x 3.5” Hot-swap HDD bays (SATA/SAS Supported)
- 2 x Hot-Swap 2.5” Storage Bays (Rear)
- 6 PCIe + 1 OCP expansion slots in a 4U rack unit
- OCP 2.0 Mezzanine (Gen3 x16 Link)
- Dual M.2 support (SATA 6Gb/s & PCI-E Gen3 x4 link)
- Control Center Management Software
- ASMB9-iKVM for KVM over Internet
- Efficient cooling with hot-swappable redundant fans and dedicated air tunnels
Technical Specification
SYSTEM |
||
Recommended Operating System |
|
|
CPU |
2 x Intel® Xeon® Scalable v1/v2 (LGA 3647/ Intel C621 PCH) Processor Family |
|
System Memory Slot |
16 x Up to 2048GB LR-DIMM 3DS / 1024GB LRDIMM / 512GB RDIMM |
|
Integrated Video Controller |
Aspeed AST2500 with 64MB VRAM |
|
Front I/O Port |
|
|
Rear I/O Port |
|
|
LED |
Front Switch/LED: 1 x Power switch/LED, 1 x Location switch/LED, 1 x Reset switch, 1 x HDD Access LED, 1 x Message LED, LAN 1-4 LED * LAN3-4 for Mezzanine card use
1 x Power switch, 1 x Q-Code/Port 80 LED, 1 x Message LED, 1 x HDD LED, 1 x Location LED |
|
Expansion Slots |
|
|
Storage Disk Drive |
|
|
RAID |
RAID 0, 1, 5, 6, 10, 50, 60 Supported |
|
Power Supply |
1+1 Redundant 800W 80PLUS Platinum Power Supply |
|
MECHANICAL |
||
Dimension |
448 mm x 660 mm x 87.5 mm (W x D x H) |
|
Mounting |
2-U 19” Standard Rack Mount |
|
ENVIRONMETAL |
||
Operating Temperature |
10°C to 35°C |
|
Storage Temperature |
-40°C to 70°C |
|
Relative Humidity |
20% to 90% non-condensing |
|
REGULATORY APPROVALS |
||
Standards |
|
