Product Description
- 1/2.8" STARVIS™ CMOS
- 30x optical zoom,16x digital zoom
- Supports detection and capture of faces, humans, and vehicles, as well as smoke and flame detection.
- Intelligent analysis: intrusion, single line crossing, double line crossing, loitering, wrong-way, illegal parking, and people counting.
- True WDR, 3D DNR, ICR, HLC, BLC, Defog
- -K: Support fiber optical interface
- Material: 316L Stainless steel, IP68 water resistant
- ATEX: II 2 G Ex db IIC T6 Gb, Ex II 2 D Ex tb IIIC T80°C Db
|
Camera |
|
|
Image Sensor |
1/2.8”Progressive Scan CMOS |
|
Max. Resolution |
5MP, 2592(H) × 1944(V) |
|
Min. illumination |
Color: 0.07 Lux @ (F1.6, AGC ON), B/W: 0.02 Lux @ (F1.6, AGC ON) |
|
Electronic Shutter |
Auto/Manual, 1/5 to 1/100,000s |
|
Day & Night |
Auto (ICR) |
|
Wide Dynamic Range |
True WDR |
|
Wiper |
Support |
|
Lens |
|
|
Focal Length |
5.3 to 159 mm, 30x Optical Zoom |
|
Max. Aperture |
F1.6 to F4.3 |
|
Angle of View |
H: 56.3° to 2.7°, V: 42.4° to 2.0° |
|
Zoom Speed |
Approx. 2.5 s |
|
Digital Zoom |
16x |
|
Iris Control |
Auto/Manual |
|
Focus Control |
Auto/Manual/Semi-automatic |
|
DORI Distance |
|
|
Detection |
104 to 3,120 m (341.2 to 10,236.2 ft) |
|
Observe |
41.6 to 1,248 m (136.5 to 4,094.5 ft) |
|
Recognize |
20.8 to 624 m (68.2 to 2,047.2 ft) |
|
Identify |
10.4 to 312 m (34.1 to 1,023.6 ft) |
|
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. |
|
|
Intelligent Analytics |
|
|
Multi-Object Detection |
Support face, human, vehicle detection and capture |
|
Smoke and Flame Detection |
Support |
|
Intelligent Analysis |
Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, Smart Motion Detection (support the accurate detection of vehicle and human) |
|
People Counting |
Support |
|
Video and Audio |
|
|
Streaming Capability |
3 Streams |
|
Stream/Frame Rate |
Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720 @25/30fps Stream2: D1, VGA, CIF @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
Stream1: 200 kbps to 12 Mbps Stream2: 100 kbps to 6 Mbps Stream3: 100 kbps to 3 Mbps |
|
Smart Encoder |
Support |
|
Region of Interest (ROI) |
Support |
|
Audio Compression |
G.711 A-law, G.711 μ-law, RAW_PCM |
|
Audio Bit Rate |
64 kbps (G.711), 128 kbps (RAW_PCM) |
|
Image |
|
|
Image Adjustment |
Brightness, Sharpness, Contrast, Saturation adjustable |
|
Scene Setting |
Indoor, Outdoor, Mirror |
|
Exposure Mode |
Auto, Manual, Shutter priority, Iris priority |
|
White Balance |
Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
|
Day/Night Setting |
Auto, Day, Night, Timer |
|
Noise Reduction |
2D/3D DNR |
|
Image Enhancement |
HLC, BLC, Defog, WDR, Anti-shake |
|
Privacy Masking |
Support 8 zones, mask color configurable |
|
Event |
|
|
Alarm Triggers |
IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
|
Event Action |
Alarm record, SMTP upload, FTP upload, Alarm output, Audible alarm output |
|
Network |
|
|
Protocols |
IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
|
Interoperability |
ONVIF (Profile S/T/G/M), SDK, CGI |
|
User/Host Level |
Up to 10 users, 3 levels: Administrator, Operator, Media user |
|
Security |
IP address filter, encrypted HTTPS, Illegal login lock, IEEE 802.1x |
|
Web Viewer |
<IE11, Chrome, Firefox, Microsoft Edge |
|
Interface |
|
|
Network Interface |
1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port |
|
Fiber Optical |
-K: 1 single module fiber interface |
|
Audio Interface |
1ch Input, 1ch Output |
|
Alarm Interface |
2ch Input, 1ch Output |
|
RS-485 |
Support |
|
CVBS Interface |
Support |
|
SD Card Slot |
Built-in, up to 256GB |
|
Reset Button |
Built-in |
|
General |
|
|
Language |
English, Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian. Default: English |
|
Power Supply |
100 to 240VAC |
|
Power Consumption |
Less than 25W |
|
Operating Temperature |
-40°C to 60°C (-40°F to 140 °F) |
|
Operating Humidity |
Less than 90% RH |
|
Ingress Protection |
IP68 |
|
Certifications |
ATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80°C Db; IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80°C Db |
|
Material |
SUS316L |
|
Dimensions |
522 × 176 × 215.1 mm (20.55 × 6.93 × 8.47 inch) |
|
Net Weight |
10 kg (22.05 lb) |
