16SFP + 8GE/SFP Combo + 2 10Gb SFP+ L2+ Stackable Managed Switch

High-density, Resilient Deployment Switch Solution for Gigabit Networks of Enterprises, Campuses and Data Centers
For the growing Gigabit network and IoT (Internet of Things) demand, PLANET has launched a new-generation, stackable Gigabit switch solution, the SGS-5220 switch series, to meet the needs of enterprises, telecoms and campuses for a large-scale network deployment. The SGS-5220-24S2XR is a Layer 2+ Stackable Managed Gigabit Switch, which supports both IPv4 and IPv6 protocols and hardware Layer 3 static routing capability, and provides 24 100/1000BASE-X slots, 8 shared Gigabit RJ45 ports, 2 10G SFP+ uplink slots and another 2 dedicated 10G SFP+ stacked interfaces for stacking with the series of switches. Up to 16 units, 384 Gigabit SFP slots and 32 10Gbps SFP+ slots can be managed by a stacking group and you can add ports and functionality as needed.

Redundant AC/DC Power Supply to Ensure Continuous Operation
The SGS-5220-24S2XR is particularly equipped with one 100~240V AC power supply unit and one 36~60V DC power supply unit to provide an enhanced, reliable and scalable redundant power supply installation. The continuous power system is specifically designed to fulfill the demands of high-tech facilities requiring the highest power integrity. With the 36~60V DC power supply, the SGS-5220-24S2XR is able to act as a telecom-level device that can be located in the electronic room.

Efficient Single IP Management
The SGS-5220 stackable managed switch series applies the advantage of the stacking technology to managing the stack group with one single IP address, which helps network managers to easily manage a stack of switches instead of connecting and setting each unit one by one. The stacking technology also enables the chassis-based switches to be integrated into the SGS-5220 series at an inexpensive cost.

Highly-reliable Stacking Ability
Through its up to 40Gbps, bi-directional high bandwidth tunnel and stacking technology, the SGS-5220-24S2XR gives the enterprises, service providers and telecoms flexible control over port density, uplinks and switch stack performance. The stack redundancy of the SGS-5220-24S2XR ensures that data integrity is retained even if one switch in the stack fails. You can even hot-swap switches without disrupting the network, which greatly simplifies the tasks of upgrading the LAN for catering to increasing bandwidth demands.

Robust Layer2 Features
The SGS-5220 series can be programmed for advanced switch management function, such as dynamic port link aggregation, Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), Layer 2/4 QoS, bandwidth control and IGMP/MLD snooping. The SGS-5220 series allows the operation of a high-speed trunk combining multiple ports. Supporting 10 trunk groups, it enables a maximum of up to 16 ports per trunk and supports connection fail-over as well.

By means of improving the technology of Optical Fiber Ethernet with highly-flexible, highly-extendable and easy-to-install features, the SGS-5220 series offers up to 10Gbps data exchange speed via optical fiber interface and the transmission distance can be extended to10km. The SGS-5220 series is the ideal solution for SMBs/enterprises to build redundant connection and establish high bandwidth for server farm.
