Product Description
- Ultra slim design 17.5mm (1SU) width
- Universal input 85~264VAC (277VAC operational)
- No load power consumption < 0.3W
- Isolation class II
- Pass Limited Power Source (LPS)
- Adjustable DC output voltage
- Short Circuit, Over Load, Over Voltage Protection
- Cooling by free air convection
- Operating Temperature -30~70C
- DIN Rail TS-35/7.5 or 15 mountable
- Over Voltage category III
- Power On LED Indicator
HDR-15 is one economical ultra slim 15W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 17.5mm(1SU) in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 85VAC to 264VAC(277VAC perational) oand conforms to EN61000-3-2, the norm the European Union regulates for harmonic current.HDR-15 is designed with plastic housing that it can effectively prevent user from electric hazards. With working efficiency up to 87%, the entire series can operate at the ambient temperature between -30 °Cand 70 under air convection. The complete protection functions and relevant certificates for home °Cautomations and industrial control apparatus (IEC62368-1, UL508, UL62368-1, EN61558-2-16) make HDR-15a very competitive power supply solution for household and industrial applications.
