Product Description
IPv6 Routing and 10G Ethernet Switch Solutions for SMBs
PLANET GS-5220-24T4XV and GS-5220-24T4XVR Layer 2+ Managed Gigabit Switches with LCD Touch Screen support both IPv4 and IPv6 protocols and hardware Layer 3 static routing capability, and provide 24 10/100/1000Mbps Gigabit Ethernet ports and 4 10Gigabit SFP+ uplink slots. The GS-5220-24T4XV series can handle extremely large amounts of data in a secure topology linking to a data center/service provider backbone or high capacity servers. They can work with a 10Gbps SFP+ server adapter to help SMBs build the 10Gbps Ethernet network providing 10Gbps NAS (Network Attached Storage) or heavy transmission of video streaming service at an affordable price.
Cybersecurity Network Solution to Minimize Security Risks
The new generation of GS-5220-24T4XV series has the cybersecurity feature to protect the switch management and enhance the security for mission-critical network without extra deployment cost and effort. The GS-5220-24T4XV expands its memory and upgrades the kernel of SSH and SSL protocols to provide strong protection against advanced threats. It includes a range of cybersecurity features such as DHCP Snooping, IP Source Guard, ARP Inspection Protection, 802.1x port-based and Mac-based network access control, RADIUS and TACACS+ user accounts management, SNMPv3 authentication, and so on to complement it as an all-security solution. The network administrator can now construct highly-secure corporate networks with considerably less time and effort than before.
Intuitive LCD Control
The GS-5220-24T4XV and GS-5220-24T4XVR come with an intuitive touch panel on its front panel to greatly promote management efficiency in large-scale networks, such as enterprises, hotels, shopping malls, government buildings, and other public areas. It also features the following special management and status functions:
- IP address, VLAN and QoS configuration
- Port management and status, and SFP information
- Troubleshooting: Cable diagnostic and remote IP ping
- Maintenance: Reboot, factory default and save configuration
Redundant Ring, Fast Recovery for Critical Network Applications
The GS-5220-24T4XVR supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, 802.1s Multiple Spanning Tree Protocol (MSTP) and dual power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments. In a certain simple ring network, the recovery time of data link can be as fast as 20ms.
Layer 2+ VLAN Static Routing and 10G Uplink Application
With the built-in robust IPv4 / IPv6 Layer 3 traffic routing protocols, the GS-5220 series ensure reliable routing between VLANs and network segments. The routing protocols can be applied by VLAN interface with up to 128 routing entries. The GS-5220 series are certainly a cost-effective and ideal solution for enterprises.
