Product Description
Hardware v. 3
Key Features
- 1 x Intel®Core® Ultra 5-125U integrated SoC Powered by 14th Generation Intel® Core processors
- Intel AI Boost support (1.4GHz Max)
- 1 x 32GB DDR5 4800MHz non-ECC unbuffered SODIMM
- 3 x 2.5G Ethernet RJ-45 + 1 x 1G Ethernet RJ-45 + Integrated WiFi-6
- 4K Four-Display support via 3 x HDMI + 1 x USB-C
- Intelligent Hardware Monitor Watchdog
- Optional WiFi and Cellular Modem by M.2 2230 Slot
- Suitable for Industrial Application with wide Operating Temperature up to 50C
|
SYSTEM |
||
|
Recommended Operating System |
|
|
|
Processor |
1 x Intel® Core® Ultra 5-125U (4.30GHz Turbo, 12 Cores, 14 Threads, 12MB Cache) Processor with Intel® AI Boost (11 Int8 NPU TOPS) |
|
|
System Memory |
1 x 32GB DDR5 4800MHz non-ECC unbuffered SODIMM, expandable to 64GB |
|
|
Video Controller |
Integrated with Intel® Deep Learning Boost (Intel® DL Boost) |
|
|
Front I/O Port |
• 2 x USB 3.1 + 2 x USB 2.0 • 2 x COM (RS-232/485) |
|
|
Rear I/O Port |
• 3 x HDMI + 1 x USB-C (Up to 4K@60Hz) • 3 x 2.5G RJ45 LAN • 1 x Audio Jack • 1 x DC-in |
|
|
Storage |
• 2TB 2.5” SATA SSD • 1 x M.2 2280 NVMe PCIe Gen4 slot |
|
|
Power Requirement |
12Vdc, 10A, 120W Power Adapter |
|
|
MECHANICAL |
||
|
Weight |
1.10kg |
|
|
Dimension |
170mm x 140mm x 58mm |
|
|
Mounting |
Desktop, and VESA |
|
|
ENVIRONMETAL |
||
|
Operating Temperature |
0°C to 50°C |
|
|
Storage Temperature |
-40°C to 85°C |
|
|
Relative Humidity |
0% to 95% non-condensing |
|
|
REGULATORY APPROVALS |
||
|
Standards |
• CE • FCC • CCC • RoHS |
|
