Product Description
-
200 watts PoE power supply
-
16 x Gigabit PoE+ ports and 2 x Gigabit SFP
-
Extend mode support remote PoE feeding up to 250m
-
VLAN mode isolate each PoE Ports for security
-
Watchdog reactivates the abnormal PD by restarting POE power
-
IEEE 802.3at / IEEE 802.3af standard compliant
-
Plug&play, simple setup with no configuration needed
Specifications
| Model | GS1020PS2 | ||
| Connector Type | 16*10/100/1000M PoE Ports + 2*Gigabit SFP Uplink Ports | ||
| Network Media (Cable) |
IEEE802.3 IEEE802.3u IEEE802.3x IEEE802.3ab IEEE802.3z |
||
|
PoE Parameters |
PoE Standard: IEEE802.3af /IEEE802.3at | ||
|
Max each port: 15.4W ( IEEE 802.3af ) Max each port：30W ( IEEE 802.3at ) |
|||
| PoE compatibility: IEEE 802.3af/at adaptive | |||
| PoE port output: DC48-55V | |||
| Power Pin : Power over spare pairs 1/2(+) , 3/6 (-) | |||
| Network Media |
10BASE-T: Cat 5E UTP(≤250 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) 1000BASE-TX: Cat5 or more UTP (≤100 meter) |
||
| Optical |
MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km |
||
| Performance Specification | Bandwidth: 52Gbps | ||
| MAC: 8K | |||
| Packet Buffer Memory: 4M | |||
| Packet Forwarding Rate: 38.7Mpps | |||
| Power Supply | Power input: AC100-240V 50/60Hz, Power Budget: 200W | ||
| LED Indicator | PWR |
Power supply indicator (Red) |
Lighting：Powered Un-Light：No Power |
| 1-16 |
RJ-45 LINK indicator (Green) |
Lighting：1000M Connect Un-Light：100M or Disconnect |
|
| 1-16 |
RJ-45 ACT indicator (Green) |
Lighting：Connecting Flashing：Data Transmit Un-Light：Disconnect |
|
| Working Environment |
Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 80℃; Operating Humidity: Max 90%, non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters) Storage Height: Max to 10,000 feet (3,000 meters) |
||
